Turning points: 7 exam questions solved step by step
What this lesson covers
- At a turning point the gradient is zero.
- Whether it is a maximum or a minimum is proved by the second derivative or the gradients either side.
At a turning point the gradient is 0
- Differentiate and set f′(x) = 0.
- Solve for every x.
- Find each y from f(x), not from f′(x).
- Show whether it is a max or a min, with a reason.
Question 1 · Achieved
- y = x² − 8x + 3
- Find the turning point and
- Show that it is a minimum.
Q1: y = x² − 8x + 3
- Gradient zero.
- y″ > 0: a minimum.
- dy/dx = 2x − 8differentiate
- 2x − 8 = 0, so x = 4gradient zero
- y = 4² − 8(4) + 3the height
- = 16 − 32 + 3 = −13
- y″ = 2 > 0a minimum
- minimum at (4, −13)
Question 2 · Achieved
- y = 5 + 6x − 3x²
- Find the turning point. Use the
- Gradient either side to classify it.
Q2: y = 5 + 6x − 3x²
- Test x = 0 and x = 2.
- + then −: a maximum.
- dy/dx = 6 − 6xdifferentiate
- 6 − 6x = 0, so x = 1gradient zero
- y = 5 + 6(1) − 3(1)² = 8
- x = 0: 6 − 0 = 6 > 0rising
- x = 2: 6 − 12 = −6 < 0falling
- maximum at (1, 8)
Question 3 · Merit
- y = x³ − 3x² − 9x + 5
- Find both turning points
- And the nature of each.
Q3: y = x³ − 3x² − 9x + 5
- Take out 3, factorise.
- Classify each with y″.
- dy/dx = 3x² − 6x − 9
- 3x² − 6x − 9 = 0gradient zero
- 3(x − 3)(x + 1) = 0take out 3, factorise
- x = 3 or x = −1
- y(3) = 27 − 27 − 27 + 5 = −22
- y(−1) = −1 − 3 + 9 + 5 = 10
- y″ = 6x − 6
- y″(3) = 12 > 0: min (3, −22)
- y″(−1) = −12 < 0: max (−1, 10)
Try it: maximum or minimum?
Question 4 · Merit
- y = x⁴ − 2x²
- Find all the turning points
- And the nature of each.
- How many are there?
Q4: y = x⁴ − 2x²
- Never divide by x.
- Factor it out instead.
- dy/dx = 4x³ − 4x
- 4x³ − 4x = 0gradient zero
- x² = 1÷ 4x loses x = 0
- 4x(x² − 1) = 0take out 4x
- 4x(x − 1)(x + 1) = 0difference of squares
- x = 0, x = 1 or x = −1
- y(0) = 0
- y(±1) = 1 − 2 = −1
Q4: the nature of each point
- One y″ for each x.
- State all three.
- (0, 0), (1, −1), (−1, −1)
- y″ = 12x² − 4differentiate again
- x = 0: y″ = −4 < 0max (0, 0)
- x = 1: y″ = 12 − 4 = 8 > 0min (1, −1)
- x = −1: y″ = 12 − 4 = 8 > 0min (−1, −1)
- max (0, 0); min (±1, −1)
Question 5 · Merit, in context
- In a Pukekohe glasshouse,
- T = 12 + 6t − 0.5t² (°C),
- t hours after 6 am (0 ≤ t ≤ 12).
- Find the highest temperature, and when.
Q5: the glasshouse
- The maximum is a T value.
- Answer with units and time.
- dT/dt = 6 − tdifferentiate
- 6 − t = 0, so t = 6gradient zero
- T = 12 + 6(6) − 0.5(6)²the height
- = 12 + 36 − 18 = 30
- T″ = −1 < 0a maximum
- t = 6: 6 am + 6 h = 12 noon
- 30 °C at 12 noon
Try it: the glasshouse
Question 6 · Excellence
- y = x³ + kx² − 24x + 2 has a
- Turning point at x = 2.
- Find k, then find the other turning
- Point. Justify the nature of both.
Q6: find k
- Turning point: gradient 0.
- Put x = 2 into dy/dx.
- dy/dx = 3x² + 2kx − 24k is a constant
- 3(2)² + 2k(2) − 24 = 0flat at x = 2
- 12 + 4k − 24 = 0
- 4k = 12, so k = 3
Q6: both turning points
- x = 2 must be a root.
- Justify both.
- y = x³ + 3x² − 24x + 2
- dy/dx = 3x² + 6x − 24 = 0
- 3(x + 4)(x − 2) = 0take out 3, factorise
- x = 2 or x = −4
- y(2) = 8 + 12 − 48 + 2 = −26
- y(−4) = −64 + 48 + 96 + 2 = 82
- y″ = 6x + 6
- x = 2: y″ = 18 > 0min (2, −26)
- x = −4: y″ = −18 < 0max (−4, 82)
Question 7 · Excellence
- y = x³ − 3x² + 3x + 1
- Find where the gradient is zero.
- Is it a turning point? Justify.
Q7: flat, but does it turn?
- y″ = 0 proves nothing.
- Test either side.
- dy/dx = 3x² − 6x + 3 = 0
- 3(x − 1)² = 0take out 3, factorise
- x = 1: y = 1 − 3 + 3 + 1 = 2
- y″ = 6x − 6 = 0 at x = 1no verdict
- x = 0: dy/dx = 3 > 0rising
- x = 2: 12 − 12 + 3 = 3 > 0rising
- (1, 2): flat, not a turning point
Common mistakes
- 2x − 8 = 0 at x = 4, so the turning point is (4, 0).Find y from the curve, not from dy/dx: y = 16 − 32 + 3 = −13, so the turning point is (4, −13).
- 4x³ − 4x = 0, divide by 4x: x² = 1, so x = ±1Dividing by 4x loses x = 0; factorise 4x(x² − 1) = 0 to get all three: x = 0, 1 and −1.
- The turning point is (4, −13). It is a minimum.Prove the nature with a reason: y″ = 2 > 0, so (4, −13) is a minimum.
- dy/dx = 0 at x = 1, so (1, 2) is a turning point.The gradient is positive on both sides of x = 1, so (1, 2) is stationary but not a turning point.
The method that solved all seven
- Find every point, then prove its nature.
| Step | How |
|---|---|
| Find x | solve f′(x) = 0, all roots |
| Find y | substitute into f, not f′ |
| f″ test | f″ < 0 max, f″ > 0 min |
| f″ = 0 | test the gradient either side |
| Either side | + then − max, − then + min |
| State it | coordinates, nature, reason |
